Radio receiver 9 Articles


	EFB-EKx	EFB-EKx-ME22	EFB-EKxW	EFB-ACL	EFB-BCD	EFB-CAN	EFB-EXP	EFB-RS232-485	EFB-USB-HID
Frequency	433 MHz \| 868 MHz	433 MHz \| 868 MHz	433 MHz \| 868 MHz	433 MHz \| 868 MHz	433 MHz \| 868 MHz	433 MHz \| 868 MHz	433 MHz \| 868 MHz	433 MHz \| 868 MHz	433 MHz \| 868 MHz
Interface	Relay (NO contact)	Relay (NO contact \| NC contact)	Relay (CO contact)	Relay (NO contact \| NC contact)	BCD	CAN-Bus 2.0A & 2.0B	Ethernet (+ RS485)	RS232 \| RS485 \| RS232-485	USB
Outputs	1 ... 8	1 ... 40	1 ... 4	2 \| 4 \| 6 \| 8	4 \| 8	1	1	1	1
Function	1:1 \| Pulse \| Changeover \| On-Off	1:1 \| Pulse \| Changeover \| On-Off	1:1 \| Pulse \| Changeover \| On-Off	1:1 \| Pulse \| Changeover \| On-Off
Code setting	Configurable	Configurable	Configurable	Configurable	Configurable	Configurable	Configurable	Configurable	Configurable
Programming interface	Pin header	Pluggable screw terminal	Pin header	Mini-USB	Pin header	Mini-USB \| Micro-USB	Ethernet	RS232	Mini-USB
Power supply	5 V \| 12 V \| 24 V DC \| 230 V AC	5 V \| 12 V \| 24 V DC \| 230 V AC	12 V DC \| 24 V DC \| 230 V AC	5 V \| 12 V \| 24 V DC \| 230 V AC	5 V \| 12 V \| 24 V DC \| 230 V AC	12 V DC \| 24 V DC	12 V DC \| 24 V DC \| 230 V AC	12 V DC \| 24 V DC \| 230 V AC	5 V \| 12 V \| 24 V DC \| 230 V AC
Protection class	Max. IP66	IP20	Max. IP66	Max. IP66	Max. IP66	Max. IP66	Max. IP66	Max. IP66	Max. IP66
Dimensions	Dep.¹	22,5 x 100 x 114,5 mm	Dep.¹	Dep.¹	Dep.¹	Dep.¹	Dep.¹	Dep.¹	Dep.¹
Mounting type	Rail TH 35 \| Surface-mounted	Rail TH 35	Rail TH 35	Rail TH 35 \| Surface-mounted	Rail TH 35 \| Surface-mounted	Rail TH 35 \| Surface-mounted	Rail TH 35 \| Surface-mounted	Rail TH 35 \| Surface-mounted	Rail TH 35 \| Surface-mounted
